Conversion from MT5 Nadaraya-Watson Envelope

Forums ProRealTime English forum ProBuilder support Conversion from MT5 Nadaraya-Watson Envelope

Viewing 6 posts - 1 through 6 (of 6 total)
  • #206791

    //+——————————————————————+
    //| nd.mq5 |
    //| Copyright 2022, MetaQuotes Ltd. |
    //| https://www.mql5.com |
    //+——————————————————————+
    #property copyright “Copyright 2022, Grasco.”
    #property version “1.00”
    #property indicator_chart_window
    #property indicator_buffers 3
    #property indicator_plots 2
    #property indicator_type1 DRAW_LINE
    #property indicator_type2 DRAW_LINE
    #property indicator_width1 2
    #property indicator_width2 2
    #property indicator_color1 Blue
    #property indicator_color2 Red
    #property indicator_applied_price PRICE_WEIGHTED
    //— input parameters
    input int Length=500; // Bars Count
    input int Bandwidth=17; // Bandwidth
    input double Multiplayer=1.5;
    // n = get the bar index

    //— indicator buffers
    double ExtUpBuffer[];
    double ExtDownBuffer[];
    double ExtCABuffer[];
    double y[]; // for calculation
    int ExtBarsHandle;
    int k = 2;
    //+——————————————————————+
    //| Custom indicator initialization function |
    //+——————————————————————+
    int OnInit(){
    //— indicator buffers mapping
    SetIndexBuffer(0,ExtUpBuffer);
    SetIndexBuffer(1,ExtDownBuffer);
    SetIndexBuffer(2,y,INDICATOR_CALCULATIONS);
    //—
    IndicatorSetInteger(INDICATOR_DIGITS,_Digits+1);
    //— sets first bar from what index will be drawn
    PlotIndexSetInteger(0,PLOT_DRAW_BEGIN,0);
    PlotIndexGetInteger(1,PLOT_DRAW_BEGIN,0);
    PlotIndexSetDouble(0, PLOT_EMPTY_VALUE, 0.0);
    PlotIndexSetDouble(1, PLOT_EMPTY_VALUE, 0.0);
    //— name for DataWindow
    string short_name=StringFormat(“Nadraya”,Length);
    IndicatorSetString(INDICATOR_SHORTNAME,short_name);
    PlotIndexSetString(0,PLOT_LABEL,short_name+” Upper”);
    PlotIndexSetString(1,PLOT_LABEL,short_name+” Lower”);

    ExtBarsHandle = iMA(_Symbol,_Period,Length,0,MODE_EMA,PRICE_WEIGHTED);
    return(INIT_SUCCEEDED);
    }
    //+——————————————————————+
    //| Custom indicator iteration function |
    //+——————————————————————+
    int OnCalculate(const int rates_total,
    const int prev_calculated,
    const int begin,
    const double &price[])
    {
    //—
    if(IsStopped()) return 0;
    int calculated=BarsCalculated(ExtBarsHandle);
    if(rates_total<calculated) return(0);
    if(rates_total<Length)
    return(0);

    int copyBars = 0;
    if (prev_calculated>rates_total || prev_calculated<=0){
    copyBars = rates_total;
    }
    else{
    copyBars = rates_total-prev_calculated;
    if(prev_calculated>0) copyBars++;
    }
    int start=prev_calculated-1;
    if(start<Length)
    start=Length;

    double sum_e = 0.0;
    for(int i=rates_total-Length; i<rates_total && !IsStopped(); i++){
    double sum = 0.0;
    double sumw= 0.0;
    for(int j = rates_total-Length;j<rates_total-1;j++){
    double w = MathExp(-(MathPow(i-j,2)/(Bandwidth*Bandwidth*2)));
    sum += price[j]*w;
    sumw += w;
    }
    double y2 = sum/sumw;
    sum_e += (MathAbs(price[i]-y2));
    y[i] = y2;
    }
    double mae = sum_e/Length*Multiplayer;
    for(int i=rates_total-Length+1; i<rates_total && !IsStopped(); i++){
    double y2 = y[i];
    double y1 = y[i-1];

    ExtUpBuffer[i]=y2+mae;
    ExtDownBuffer[i]=y2-mae;
    //Print(mae);
    //Print(y[i]);
    }
    //— return value of prev_calculated for next call
    return(rates_total);
    }
    //+——————————————————————+

    #206793
    JS

    Hi @wrox

    This one was among my indicators…

    I don’t know where it originally came from…

    1 user thanked author for this post.
    #206795

    Topic of interest, including discussion repainting vs non-repainting:

    https://www.prorealcode.com/topic/conversion-from-trading-view-nadaraya-watson-envelope/#post-196081

    code in post #196311 of linked topic

    #206801

    Great work! I need to translate to easy language now. Thanks!!!

    #206849
    JS

    The code above was the non-repainting version of Nicolas…

    #206915

    Bonjour @JS et Nicolas,

    Merci pour ce code. Comment peut-on faire pour qu’une valeur soit renvoyée ? La valeur des points hauts et bas de la bande.
    Merci d’avance de votre aide.
