Et pour les lignes fractales :
#property description “An indicator that alerts and draws a horizontal line to mark whenever a fractal is engulfed by a candle close before another fractal prints in the same direction.”
#property strict
#property indicator_chart_window
#property indicator_buffers 2
input uchar LongArrowCode = 217;
input uchar ShortArrowCode = 218;
input int ArrowSize = 8;
input int LineWidth = 1;
input ENUM_LINE_STYLE LineStyle = STYLE_SOLID;
input color LongColour = clrBlue;
input color ShortColour = clrPeru;
input bool ShowComments = true;
input bool SendEmail = false;
input bool SendNotifications = false;
input bool Alerts = false;
input string AlertSound = “alert.wav”;
input bool ScreenShots = false;
double UpBuff[];
double DownBuff[];
double Vd[];
int Vi[150][150],Lines[10],LabelFontSize,tf;
color Colour[9];
datetime NewCandle;
ENUM_TIMEFRAMES TF[]={PERIOD_CURRENT,PERIOD_M1,PERIOD_M2,PERIOD_M3,PERIOD_M4,PERIOD_M5,PERIOD_M6,PERIOD_M10,PERIOD_M12,PERIOD_M15,PERIOD_M20,PERIOD_M30,PERIOD_H1,PERIOD_H2,PERIOD_H3,PERIOD_H4,PERIOD_H6,PERIOD_H8,PERIOD_H12,PERIOD_D1,PERIOD_W1,PERIOD_MN1};
string TimeFr[]={“0″,”M1″,”M2″,”M3″,”M4″,”M5″,”M6″,”M10″,”M12″,”M15″,”M20″,”M30″,”H1″,”H2″,”H3″,”H4″,”H6″,”H8″,”H12″,”D1″,”W1″,”MN”};
string Vs[150][150],TradeComment,LabelFontType,Prefix,Suffix;
void OnInit()
{int t1,t2,t3,t4;
uchar Char[];
string s7;
SetIndexBuffer(0,UpBuff);
SetIndexBuffer(1,DownBuff);
SetIndexStyle(0,DRAW_NONE);
SetIndexStyle(1,DRAW_NONE);
SetIndexEmptyValue(0,0.0);
SetIndexEmptyValue(1,0.0);
tf=0; t1=1; while(t1<=21 && tf==0) {tf=(PeriodSeconds(PERIOD_CURRENT)==PeriodSeconds(TF[t1]))*t1; t1++;}
Colour[1]=LongColour; Colour[2]=ShortColour; Colour[3]=16777215;
TradeComment=”LineFractal”; LabelFontSize=10; LabelFontType=”Segoe UI”; t2=StringToCharArray(Symbol(),Char,0,-1,CP_UTF8)-2;
t3=-1; t4=-1; t1=0; while(t1<=t2) {if (t3==-1 && Char[t1]>=65 && Char[t1]<=90) {t3=t1;} if (t3!=-1 && t4==-1 && (Char[t1]<65 || Char[t1]>90)) {t4=t1;} t1++;}
Prefix=””; if (t3>0) {Prefix=StringSubstr(Symbol(),0,t3);} Suffix=””; if (t4>0) {Suffix=StringSubstr(Symbol(),t4,0);}
t1=StringLen(Symbol())-StringLen(Prefix)-StringLen(Suffix); Vs[30][1]=StringSubstr(Symbol(),StringLen(Prefix),t1);
s7=StringConcatenate(” “,Vs[30][1],” “,TimeFr[tf]); Vs[30][4]=StringConcatenate(StringSubstr(TradeComment,0,27-StringLen(s7)),s7);
t1=0; while(t1<=100) {Vs[41][t1]=StringConcatenate(TradeComment,” “,t1); t1++;}
Vs[32][1]=”Long”; Vs[32][2]=”Short”; Vs[32][3]=”Up”; Vs[32][4]=”Down”;
}
void OnDeinit(const int reason) {if (!IsTesting()) {RemoveObjects(TradeComment);}}
int OnCalculate(const int rates_total,
const int prev_calculated,
const datetime &time[],
const double &open[],
const double &high[],
const double &low[],
const double &close[],
const long &tick_volume[],
const long &volume[],
const int &spread[])
{int t1,t2,t3;
bool b1,b2,b3;
datetime h1;
double d1;
string s1,s2;
b2=(NewCandle!=time[0]); if (b2) {t1=1; while(t1<=4) {Lines[t1]=0; t1++;}} t1=1; while(t1<=rates_total-1 && b2)
{UpBuff[t1]=0; d1=iFractals(Symbol(),PERIOD_CURRENT,MODE_UPPER,t1); s1=StringConcatenate(TradeComment,” up arrow “,TimeToString(time[t1]));
s2=StringConcatenate(TradeComment,” up line “,TimeToString(time[t1]));
if (d1==0) {if (ObjectFind(0,s1)!=-1) {ObjectDelete(0,s1);} if (ObjectFind(0,s2)!=-1) {ObjectDelete(0,s2);}}
if (d1>0) {DrawText(s1,CharToString(LongArrowCode),time[t1],d1,ArrowSize,”Wingdings”,Colour[1],ANCHOR_LOWER);
b1=false; b3=false; t2=t1-1; while(t2>0 && !b3 && !b1) {b1=(close[t2]>=d1); b3=(iFractals(Symbol(),PERIOD_CURRENT,MODE_UPPER,t2)>0); t2–;}
t3=t2+b1; if (!b1 && t2>0 && ObjectFind(0,s2)!=-1) {ObjectDelete(0,s2);}
if (b1 || t2==0) {Lines[1]+=1; UpBuff[t1]=d1; if (t2==0 && b1) {OrderAlert(1,t2+1);}
h1=time[t3]; Lines[3]+=(int)(t2==0); DrawTrendLine(s2,0,h1,d1,time[t1],d1,Colour[1],LineStyle,LineWidth);}}
DownBuff[t1]=0; d1=iFractals(Symbol(),PERIOD_CURRENT,MODE_LOWER,t1); s1=StringConcatenate(TradeComment,” down arrow “,TimeToString(time[t1]));
s2=StringConcatenate(TradeComment,” down line “,TimeToString(time[t1]));
if (d1==0) {if (ObjectFind(0,s1)!=-1) {ObjectDelete(0,s1);} if (ObjectFind(0,s2)!=-1) {ObjectDelete(0,s2);}}
if (d1>0) {DrawText(s1,CharToString(ShortArrowCode),time[t1],d1,ArrowSize,”Wingdings”,Colour[2],ANCHOR_UPPER);
b1=false; b3=false; t2=t1-1; while(t2>0 && !b3 && !b1) {b1=(close[t2]<=d1); b3=(iFractals(Symbol(),PERIOD_CURRENT,MODE_LOWER,t2)>0); t2–;}
t3=t2+b1; if (!b1 && t2>0 && ObjectFind(0,s2)!=-1) {ObjectDelete(0,s2);}
if (b1 || t2==0) {Lines[2]+=1; DownBuff[t1]=d1; if (t2==0 && b1) {OrderAlert(2,t2+1);}
h1=time[t3]; Lines[4]+=(int)(t2==0); DrawTrendLine(s2,0,h1,d1,time[t1],d1,Colour[2],LineStyle,LineWidth);}}
t1++;} NewCandle=time[0]; ScreenInfo();
return(rates_total);}
void DrawText(string r6,string r7,datetime x6,double f7,int x5,string r8,color x3,int x7)
{if (r7==”” && ObjectFind(0,r6)!=-1) {ObjectDelete(0,r6);}
if (r7!=””) {if (ObjectFind(0,r6)==-1) {ObjectCreate(0,r6,OBJ_TEXT,0,0,0);} ObjectSetString(0,r6,OBJPROP_TEXT,r7); ObjectSetInteger(0,r6,OBJPROP_TIME,x6);
ObjectSetDouble(0,r6,OBJPROP_PRICE,f7); ObjectSetInteger(0,r6,OBJPROP_FONTSIZE,x5); ObjectSetString(0,r6,OBJPROP_FONT,r8); ObjectSetInteger(0,r6,OBJPROP_COLOR,x3);
ObjectSetInteger(0,r6,OBJPROP_ANCHOR,x7);}}
void DrawTrendLine(string r6,int x1,datetime x6,double f6,datetime x7,double f7,color x3,int x4,int x5)
{if (f6==0 && f7==0 && ObjectFind(0,r6)!=-1) {ObjectDelete(0,r6);}
if (f6>0 || f7>0) {if (ObjectFind(0,r6)==-1) {ObjectCreate(0,r6,OBJ_TREND,x1,0,0,0,0); ObjectSetInteger(0,r6,OBJPROP_RAY,false);}
ObjectSetInteger(0,r6,OBJPROP_TIME,x6); ObjectSetInteger(0,r6,OBJPROP_TIME,1,x7); ObjectSetDouble(0,r6,OBJPROP_PRICE,f6); ObjectSetDouble(0,r6,OBJPROP_PRICE,1,f7);
ObjectSetInteger(0,r6,OBJPROP_COLOR,x3); ObjectSetInteger(0,r6,OBJPROP_STYLE,x4); ObjectSetInteger(0,r6,OBJPROP_WIDTH,x5);}}
void RemoveObjects(string r6)
{int t1;
t1=ObjectsTotal(); while(t1>=0) {if (StringFind(ObjectName(t1),r6,0)!=-1) {ObjectDelete(0,ObjectName(t1));} t1–;}}
void DrawLabel(string r6,string r7,ENUM_BASE_CORNER x4,int x1,int x2,int x5,string r8,color x3,bool b6)
{if (r7==”” && ObjectFind(0,r6)!=-1) {ObjectDelete(0,r6);}
if (r7!=””) {if (ObjectFind(0,r6)==-1) {ObjectCreate(0,r6,OBJ_LABEL,0,0,0);} ObjectSetInteger(0,r6,OBJPROP_CORNER,x4); ObjectSetString(0,r6,OBJPROP_TEXT,r7);
ObjectSetInteger(0,r6,OBJPROP_FONTSIZE,x5); ObjectSetString(0,r6,OBJPROP_FONT,r8); ObjectSetInteger(0,r6,OBJPROP_COLOR,x3); ObjectSetInteger(0,r6,OBJPROP_BACK,b6);
ObjectSetInteger(0,r6,OBJPROP_XDISTANCE,x1); ObjectSetInteger(0,r6,OBJPROP_YDISTANCE,x2);}}
void OrderAlert(int x7,int x8)
{string s1;
s1=StringConcatenate(Vs[32][x7+2],” farctal has been engulfed at “,TimeToString(Time[x8]));
if (SendEmail) {SendMail(Vs[30][4],s1);}
if (SendNotifications) {SendNotification(StringConcatenate(s1,”, “,Vs[30][4]));}
if (ScreenShots) {ChartScreenShot(0,StringConcatenate(TimeFr[tf],Vs[30][1],TimeToString(Time[x8])),1920,1080,ALIGN_RIGHT);}
if (Alerts) {Alert(StringConcatenate(s1,”, “,Vs[30][4])); if (AlertSound!=””) {PlaySound(AlertSound);}}}
void ScreenInfo()
{int t1,t2,t7;
double d1;
if (ShowComments) {t1=0; while(t1<=100) {Vs[40][t1]=””; Vi[32][t1]=Colour[3]; t1++;}
d1=(double)(Lines[3]+Lines[4])/(Lines[1]+Lines[2]); t7+=1; Vs[40][t7]=StringConcatenate(“Total lines “,Lines[1]+Lines[2]);
t1=1; while(t1<=2) {d1=Lines[t1+2]/Lines[t1]; t7+=1; Vs[40][t7]=StringConcatenate(Vs[32][t1+2],” lines “,Lines[t1]); t1++;}
t2=14; t1=0; while(t1<=100) {DrawLabel(Vs[41][t1],Vs[40][t1],CORNER_LEFT_UPPER,2,t2,LabelFontSize,LabelFontType,Vi[32][t1],false);
t2+=(int)(Vs[40][t1]!=””)*14; t1++;}}}
.
.
