Liquidity Pools

Dejo aquí la traducción de un indicador de tradingview que me parece interesante.

https://es.tradingview.com/v/yXJBwibN/

Este es el código traducido (tenéis la explicación en la librería de códigos)

Liquidity Pools

//----------------------------------------------
//PRC_Liquidity Pools [LuxAlgo]
//Pools de liquidez: niveles tocados N veces + volumen atrapado
//version = 1
//02.06.2026
//Ivan Gonzalez @ www.prorealcode.com
//Sharing ProRealTime knowledge
//----------------------------------------------
defparam drawonlastbaronly = true

// === INPUTS ===
cNum     = 2     // Zone Contact Amount (contactos minimos para validar el pool)
gapCount = 5     // Bars Required Between Each Contact
waitBars = 10    // Confirmation Bars (espera antes de dibujar la zona)
volTog   = 1     // 1 = mostrar etiquetas de volumen
maxZones = 10    // cap de zonas vivas por lado

// === COLORES (RGB) ===
bullR = 8
bullG = 153
bullB = 129
bearR = 242
bearG = 54
bearB = 69

MAXZ = 20        // cota superior de slots del pool por lado

// === VELA ACTUAL ===
cTop = max(open, close)
cBot = min(open, close)

// === ESTADO PERSISTENTE (init en la primera barra) ===
// Solo se conservan los campos del UDT 'data' realmente usados:
//   referencia ALTA (resistencia): hstH (mecha=top caja), hstT (cuerpo=nivel/linea), hstBi (x izq)
//   referencia BAJA (soporte):     lstB (cuerpo=nivel/linea), lstL (mecha=bottom caja), lstBi (x izq)
if barindex = 0 then
   hstH  = high
   hstT  = cTop
   hstBi = barindex
   lstB  = cBot
   lstL  = low
   lstBi = barindex
   hCount = 0
   lCount = 0
   lastHwick = barindex
   lastLwick = barindex
   hiVol = 0
   loVol = 0
   bsHw = 0
   bsLw = 0
endif

// === 1. RESET DE REFERENCIA ALTA ===
if high > hstH and (cTop > hstH or cTop < hstT) then
   if hCount > 1 then
      lstB  = cBot
      lstL  = low
      lstBi = barindex
      loVol = 0
      lCount = 0
   endif
   hstH  = high
   hstT  = cTop
   hstBi = barindex
   hiVol = 0
   hCount = 1
   lastHwick = barindex
endif

// === 2. RESET DE REFERENCIA BAJA ===
if low < lstL and (cBot < lstL or cBot > lstB) then
   if lCount > 1 then
      hstH  = high
      hstT  = cTop
      hstBi = barindex
      hiVol = 0
      hCount = 0
   endif
   lstB  = cBot
   lstL  = low
   lstBi = barindex
   loVol = 0
   lCount = 1
   lastLwick = barindex
endif

// === 3. CONTEO DE CONTACTOS ===

hWick = 0
if high > hstT and cTop <= hstT then
   hWick = 1
endif
lWick = 0
if low < lstB and cBot >= lstB then
   lWick = 1
endif

// Se confirma el contacto una barra despues.

if barindex > 2 and hWick[1] = 1 and hstT[1] = hstT[2] and bsHw[1] > gapCount then
   hCount = hCount + 1
   lastHwick = barindex - 1
endif
if barindex > 2 and lWick[1] = 1 and lstB[1] = lstB[2] and bsLw[1] > gapCount then
   lCount = lCount + 1
   lastLwick = barindex - 1
endif

// Barras desde el ultimo contacto
bsHw = abs(lastHwick - barindex)
bsLw = abs(lastLwick - barindex)

// === 4. TRACKING DE EXTREMOS ===
if high > hstH then
   hstH = high
endif
if low < lstL then
   lstL = low
endif

// === 5. VOLUMEN ATRAPADO ===
rng = high - low
if rng > 0 then
   hstVol = max(high - hstT, 0) / rng * volume
   lstVol = max(lstB - low, 0) / rng * volume
else
   hstVol = 0
   lstVol = 0
endif
hiVol = hiVol + hstVol
loVol = loVol + lstVol

// === 6. CONFIRMACION + CREACION ZONA BEAR (resistencia) ===

bearTrig = 0
if hCount >= cNum and bsHw > waitBars and bsHw[1] <= waitBars and close < hstT then
   bearTrig = 1
endif

if bearTrig = 1 then
   // Merge: si el nivel cae dentro de una zona bear viva, fusiona en vez de duplicar.
   mergedB = 0
   for i = 0 to MAXZ - 1 do
      if $bzAct[i] = 1 and mergedB = 0 then
         if hstT <= $bzTop[i] and hstT >= $bzLvl[i] then
            if hstH > $bzTop[i] then
               $bzTop[i] = hstH
            endif
            $bzRight[i] = barindex
            $bzVol[i] = $bzVol[i] + hiVol
            $bzBorn[i] = barindex
            mergedB = 1
         endif
      endif
   next
   // Si no fusiona: slot libre o, si se alcanzo el cap, eviccion FIFO (menor born).
   if mergedB = 0 then
      slot = -1
      cnt = 0
      oldIdx = -1
      oldBorn = 0
      for i = 0 to MAXZ - 1 do
         if $bzAct[i] = 1 then
            cnt = cnt + 1
            if oldIdx = -1 or $bzBorn[i] < oldBorn then
               oldBorn = $bzBorn[i]
               oldIdx = i
            endif
         else
            if slot = -1 then
               slot = i
            endif
         endif
      next
      if cnt >= maxZones then
         slot = oldIdx
      endif
      if slot = -1 then
         slot = oldIdx
      endif
      $bzLvl[slot]   = hstT
      $bzTop[slot]   = hstH
      $bzLeft[slot]  = hstBi
      $bzRight[slot] = barindex
      $bzVol[slot]   = hiVol
      $bzAct[slot]   = 1
      $bzState[slot] = 0
      $bzBorn[slot]  = barindex
   endif
endif

// === 7. CONFIRMACION + CREACION ZONA BULL (soporte) ===
bullTrig = 0
if lCount >= cNum and bsLw > waitBars and bsLw[1] <= waitBars and close > lstB then
   bullTrig = 1
endif

if bullTrig = 1 then
   mergedL = 0
   for i = 0 to MAXZ - 1 do
      if $lzAct[i] = 1 and mergedL = 0 then
         if lstB >= $lzBot[i] and lstB <= $lzLvl[i] then
            if lstL < $lzBot[i] then
               $lzBot[i] = lstL
            endif
            $lzRight[i] = barindex
            $lzVol[i] = $lzVol[i] + loVol
            $lzBorn[i] = barindex
            mergedL = 1
         endif
      endif
   next
   if mergedL = 0 then
      slot = -1
      cnt = 0
      oldIdx = -1
      oldBorn = 0
      for i = 0 to MAXZ - 1 do
         if $lzAct[i] = 1 then
            cnt = cnt + 1
            if oldIdx = -1 or $lzBorn[i] < oldBorn then
               oldBorn = $lzBorn[i]
               oldIdx = i
            endif
         else
            if slot = -1 then
               slot = i
            endif
         endif
      next
      if cnt >= maxZones then
         slot = oldIdx
      endif
      if slot = -1 then
         slot = oldIdx
      endif
      $lzLvl[slot]   = lstB
      $lzBot[slot]   = lstL
      $lzLeft[slot]  = lstBi
      $lzRight[slot] = barindex
      $lzVol[slot]   = loVol
      $lzAct[slot]   = 1
      $lzState[slot] = 0
      $lzBorn[slot]  = barindex
   endif
endif

// === 8. MITIGACION / DELECION ===
// Bear: barrida cuando el cierre supera el extremo superior de la zona.
for i = 0 to MAXZ - 1 do
   if $bzAct[i] = 1 then
      if close > $bzTop[i] then
         if $bzState[i] < 0 then
            $bzAct[i] = 0
         endif
         $bzState[i] = $bzState[i] - 1
      else
         $bzState[i] = 0
      endif
   endif
next
// Bull: barrida cuando el cierre pierde el extremo inferior de la zona.
for i = 0 to MAXZ - 1 do
   if $lzAct[i] = 1 then
      if close < $lzBot[i] then
         if $lzState[i] < 0 then
            $lzAct[i] = 0
         endif
         $lzState[i] = $lzState[i] - 1
      else
         $lzState[i] = 0
      endif
   endif
next

// === 9. RENDER (solo en la ultima barra) ===
if islastbarupdate then

   // --- ZONAS BEAR (resistencia / liquidez en maximos) ---
   for i = 0 to MAXZ - 1 do
      if $bzAct[i] = 1 then
         lvl  = $bzLvl[i]
         topY = $bzTop[i]
         lft  = $bzLeft[i]
         rgt  = $bzRight[i]
         drawrectangle(lft, topY, rgt, lvl) coloured(bearR, bearG, bearB, 0) fillcolor(bearR, bearG, bearB, 51)
         drawsegment(lft, lvl, barindex, lvl) coloured(bearR, bearG, bearB) style(line, 1)
         if volTog = 1 then
            vv = $bzVol[i]
            if vv >= 1000000 then
               vShow = round(vv / 100000) / 10
               drawtext("#vShow#M", barindex + 3, lvl) coloured(bearR, bearG, bearB)
            elsif vv >= 1000 then
               vShow = round(vv / 100) / 10
               drawtext("#vShow#K", barindex + 3, lvl) coloured(bearR, bearG, bearB)
            else
               vShow = round(vv)
               drawtext("#vShow#", barindex + 3, lvl) coloured(bearR, bearG, bearB)
            endif
         endif
      endif
   next

   // --- ZONAS BULL (soporte / liquidez en minimos) ---
   for i = 0 to MAXZ - 1 do
      if $lzAct[i] = 1 then
         lvl  = $lzLvl[i]
         botY = $lzBot[i]
         lft  = $lzLeft[i]
         rgt  = $lzRight[i]
         drawrectangle(lft, lvl, rgt, botY) coloured(bullR, bullG, bullB, 0) fillcolor(bullR, bullG, bullB, 51)
         drawsegment(lft, lvl, barindex, lvl) coloured(bullR, bullG, bullB) style(line, 1)
         if volTog = 1 then
            vv = $lzVol[i]
            if vv >= 1000000 then
               vShow = round(vv / 100000) / 10
               drawtext("#vShow#M", barindex + 3, lvl) coloured(bullR, bullG, bullB)
            elsif vv >= 1000 then
               vShow = round(vv / 100) / 10
               drawtext("#vShow#K", barindex + 3, lvl) coloured(bullR, bullG, bullB)
            else
               vShow = round(vv)
               drawtext("#vShow#", barindex + 3, lvl) coloured(bullR, bullG, bullB)
            endif
         endif
      endif
   next

endif

return
