Modified PVO VO to match Elder Impulsive MACD

This topic has 2 replies, 2 voices, and was last updated 3 days ago by JS.

Viewing 3 posts - 1 through 3 (of 3 total)

09/10/2025 at 5:12 PM #250649

Sagal

Hi all, I don’t manage myself or with the IA to modify the original PVO VO indicator to match in color and time the Elder Impulse MACD that I found couple of years back somewhere here. This is what the IA provide that is not working, I have error message when trying to save with something in line with ending with “Return”.

//@version=13
// PVO with Elder Impulse Coloring & Divergence
DefParam DrawOnLastBarOnly = True

// Parameters (Fibonacci-based)
ShortPeriod = 13
LongPeriod = 34
SignalPeriod = 5
TrendPeriod = 13

// Initialize variables for divergence detection (CRITICAL in PRT)
hi = 0
lo = 100000
hico = 0
lowco = 100000
sto1b = 0
sto2b = 0
sto1h = 100000
sto2h = 100000
p1b = 0
p2b = 0
p3b = 0
p4b = 0
p1h = 100000
p2h = 100000
p3h = 100000
p4h = 100000
hico1 = 0
lowco1 = 100000

// Core PVO Calculation
EMAShort = ExponentialAverage[ShortPeriod](Volume)
EMALong = ExponentialAverage[LongPeriod](Volume)
PVO = ((EMAShort – EMALong) / EMALong) * 100
SignalLine = ExponentialAverage[SignalPeriod](PVO)
Histogram = PVO – SignalLine

// Elder Impulse Coloring Logic
TrendEMA = ExponentialAverage[TrendPeriod](Close)
ImpulseUp = 0
ImpulseDown = 0
ImpulseNeutral = 0

IF TrendEMA > TrendEMA[1] AND Histogram > Histogram[1] THEN
ImpulseUp = Histogram
ELSIF TrendEMA < TrendEMA[1] AND Histogram < Histogram[1] THEN
ImpulseDown = Histogram
ELSE
ImpulseNeutral = Histogram
ENDIF

// ZeroLag Volume Divergence Detection
EMAShort1 = ExponentialAverage[ShortPeriod](Volume)
EMAShort2 = ExponentialAverage[ShortPeriod](EMAShort1)
DiffShort = EMAShort1 – EMAShort2
ZeroLagShort = EMAShort1 + DiffShort

EMALong1 = ExponentialAverage[LongPeriod](Volume)
EMALong2 = ExponentialAverage[LongPeriod](EMALong1)
DiffLong = EMALong1 – EMALong2
ZeroLagLong = EMALong1 + DiffLong

ZeroLagPVO = ZeroLagShort – ZeroLagLong

SignalZL1 = ExponentialAverage[SignalPeriod](ZeroLagPVO)
SignalZL2 = ExponentialAverage[SignalPeriod](SignalZL1)
DiffZL = SignalZL1 – SignalZL2
SignalZL = SignalZL1 + DiffZL

// Divergence Logic
x = ZeroLagPVO
y = SignalZL
BullDiv = 0
BearDiv = 0

// BEARISH DIVERGENCES PVO (as in your working MACD code)
hi = max(hi, x)
hico = max(hico, max(High, High[1]))

IF x CROSSES UNDER y THEN
sto2b = sto1b
sto1b = hi
hi = 0
p3b = p1b
p2b = max(p1b, hico1)
p1b = max(Highest[3](High), hico)
IF p2b = p1b THEN
p2b = max(p3b, p4b)
ENDIF
hico = 0
hico1 = 0
ENDIF

IF x < y THEN
p4b = hico1
hico1 = max(hico1, High)
ENDIF

IF p1b > p2b AND sto1b < sto2b AND x CROSSES UNDER y AND x < x[1] THEN
BearDiv = Histogram
ENDIF

// BULLISH PVO DIVERGENCES
lo = min(lo, x)
lowco = min(lowco, min(Low, Low[1]))

IF x CROSSES OVER y THEN
sto2h = sto1h
sto1h = lo
lo = 100000
p3h = p1h
p2h = min(p1h, lowco1)
p1h = min(Lowest[3](Low), lowco)
IF p2h = p1h THEN
p2h = min(p3h, p4h)
ENDIF
lowco = 100000
lowco1 = 100000
ENDIF

IF x > y THEN
p4h = lowco1
lowco1 = min(lowco1, Low)
ENDIF

IF p1h < p2h AND sto1h > sto2h AND x CROSSES OVER y AND x > x[1] THEN
BullDiv = Histogram
ENDIF

// RETURN statement (MUST be the last line)
RETURN ImpulseUp COLOURED(0,255,0) AS “Impulse Up (Green)”,
ImpulseDown COLOURED(255,0,0) AS “Impulse Down (Red)”,
ImpulseNeutral COLOURED(128,128,128) AS “Impulse Neutral (Gray)”,
BullDiv COLOURED(0,180,0) AS “Bullish Divergence”,
BearDiv COLOURED(180,0,0) AS “Bearish Divergence”,
Histogram AS “PVO Histogram”,
0 AS “Zero Line”

Sagal

Participant

Topics: 2

Replies: 4

Been thanked: 1 time

09/10/2025 at 5:33 PM #250650

Sagal

Clarification. Maybe it is more for curiosity if you can fix the issue of the code. In the original PVO & VO I have already modified short term MA to 13, long term to 34 and signal to 5. The colors match as well. So at the end the modification I made on the origina PVO & VO seems to be fine. I didn’t modify the default value of Elder Impulse MACD so the purpose of matching is not pursued anymore.

Sagal

Participant

Topics: 2

Replies: 4

Been thanked: 1 time

09/10/2025 at 6:44 PM #250656

Hi,
The word “Histogram” is a reserved keyword in PRT, I modified the code and replaced “Histogram” with “xHistogram”…

//@version=13
// PVO with Elder Impulse Coloring & Divergence
DefParam DrawOnLastBarOnly = True

// Parameters (Fibonacci-based)
ShortPeriod = 13
LongPeriod = 34
SignalPeriod = 5
TrendPeriod = 13

// Initialize variables for divergence detection (CRITICAL in PRT)
hi = 0
lo = 100000
hico = 0
lowco = 100000
sto1b = 0
sto2b = 0
sto1h = 100000
sto2h = 100000
p1b = 0
p2b = 0
p3b = 0
p4b = 0
p1h = 100000
p2h = 100000
p3h = 100000
p4h = 100000
hico1 = 0
lowco1 = 100000

// Core PVO Calculation
EMAShort = ExponentialAverage[ShortPeriod](Volume)
EMALong = ExponentialAverage[LongPeriod](Volume)
PVO = ((EMAShort - EMALong) / EMALong) * 100
SignalLine = ExponentialAverage[SignalPeriod](PVO)
xHistogram = PVO - SignalLine

// Elder Impulse Coloring Logic
TrendEMA = ExponentialAverage[TrendPeriod](Close)
ImpulseUp = 0
ImpulseDown = 0
ImpulseNeutral = 0

IF TrendEMA > TrendEMA[1] AND xHistogram > xHistogram[1] THEN
ImpulseUp = xHistogram
ELSIF TrendEMA < TrendEMA[1] AND xHistogram < xHistogram[1] THEN
ImpulseDown = xHistogram
ELSE
ImpulseNeutral = xHistogram
ENDIF

// ZeroLag Volume Divergence Detection
EMAShort1 = ExponentialAverage[ShortPeriod](Volume)
EMAShort2 = ExponentialAverage[ShortPeriod](EMAShort1)
DiffShort = EMAShort1 - EMAShort2
ZeroLagShort = EMAShort1 + DiffShort

EMALong1 = ExponentialAverage[LongPeriod](Volume)
EMALong2 = ExponentialAverage[LongPeriod](EMALong1)
DiffLong = EMALong1 - EMALong2
ZeroLagLong = EMALong1 + DiffLong

ZeroLagPVO = ZeroLagShort - ZeroLagLong

SignalZL1 = ExponentialAverage[SignalPeriod](ZeroLagPVO)
SignalZL2 = ExponentialAverage[SignalPeriod](SignalZL1)
DiffZL = SignalZL1 - SignalZL2
SignalZL = SignalZL1 + DiffZL

// Divergence Logic
x = ZeroLagPVO
y = SignalZL
BullDiv = 0
BearDiv = 0

// BEARISH DIVERGENCES PVO (as in your working MACD code)
hi = max(hi, x)
hico = max(hico, max(High, High[1]))

IF x CROSSES UNDER y THEN
sto2b = sto1b
sto1b = hi
hi = 0
p3b = p1b
p2b = max(p1b, hico1)
p1b = max(Highest[3](High), hico)
IF p2b = p1b THEN
p2b = max(p3b, p4b)
ENDIF
hico = 0
hico1 = 0
ENDIF

IF x < y THEN
p4b = hico1
hico1 = max(hico1, High)
ENDIF

IF p1b > p2b AND sto1b < sto2b AND x CROSSES UNDER y AND x < x[1] THEN
BearDiv = xHistogram
ENDIF

// BULLISH PVO DIVERGENCES
lo = min(lo, x)
lowco = min(lowco, min(Low, Low[1]))

IF x CROSSES OVER y THEN
sto2h = sto1h
sto1h = lo
lo = 100000
p3h = p1h
p2h = min(p1h, lowco1)
p1h = min(Lowest[3](Low), lowco)
IF p2h = p1h THEN
p2h = min(p3h, p4h)
ENDIF
lowco = 100000
lowco1 = 100000
ENDIF

IF x > y THEN
p4h = lowco1
lowco1 = min(lowco1, Low)
ENDIF

IF p1h < p2h AND sto1h > sto2h AND x CROSSES OVER y AND x > x[1] THEN
BullDiv = xHistogram
ENDIF

// RETURN statement (MUST be the last line)
RETURN ImpulseUp COLOURED(0,255,0) AS "Impulse Up (Green)",ImpulseDown COLOURED(255,0,0) AS "Impulse Down (Red)",ImpulseNeutral COLOURED(128,128,128) AS "Impulse Neutral (Gray)",BullDiv COLOURED(0,180,0) AS "Bullish Divergence",BearDiv COLOURED(180,0,0) AS "Bearish Divergence",xHistogram AS "PVO Histogram",0 AS "Zero Line"

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

//@version=13

// PVO with Elder Impulse Coloring & Divergence

DefParam DrawOnLastBarOnly = True

// Parameters (Fibonacci-based)

ShortPeriod = 13

LongPeriod = 34

SignalPeriod = 5

TrendPeriod = 13

// Initialize variables for divergence detection (CRITICAL in PRT)

hi = 0

lo = 100000

hico = 0

lowco = 100000

sto1b = 0

sto2b = 0

sto1h = 100000

sto2h = 100000

p1b = 0

p2b = 0

p3b = 0

p4b = 0

p1h = 100000

p2h = 100000

p3h = 100000

p4h = 100000

hico1 = 0

lowco1 = 100000

// Core PVO Calculation

EMAShort = ExponentialAverage[ShortPeriod](Volume)

EMALong = ExponentialAverage[LongPeriod](Volume)

PVO = ((EMAShort - EMALong) / EMALong) * 100

SignalLine = ExponentialAverage[SignalPeriod](PVO)

xHistogram = PVO - SignalLine

// Elder Impulse Coloring Logic

TrendEMA = ExponentialAverage[TrendPeriod](Close)

ImpulseUp = 0

ImpulseDown = 0

ImpulseNeutral = 0

IF TrendEMA > TrendEMA[1] AND xHistogram > xHistogram[1] THEN

ImpulseUp = xHistogram

ELSIF TrendEMA < TrendEMA[1] AND xHistogram < xHistogram[1] THEN

ImpulseDown = xHistogram

ELSE

ImpulseNeutral = xHistogram

ENDIF

// ZeroLag Volume Divergence Detection

EMAShort1 = ExponentialAverage[ShortPeriod](Volume)

EMAShort2 = ExponentialAverage[ShortPeriod](EMAShort1)

DiffShort = EMAShort1 - EMAShort2

ZeroLagShort = EMAShort1 + DiffShort

EMALong1 = ExponentialAverage[LongPeriod](Volume)

EMALong2 = ExponentialAverage[LongPeriod](EMALong1)

DiffLong = EMALong1 - EMALong2

ZeroLagLong = EMALong1 + DiffLong

ZeroLagPVO = ZeroLagShort - ZeroLagLong

SignalZL1 = ExponentialAverage[SignalPeriod](ZeroLagPVO)

SignalZL2 = ExponentialAverage[SignalPeriod](SignalZL1)

DiffZL = SignalZL1 - SignalZL2

SignalZL = SignalZL1 + DiffZL

// Divergence Logic

x = ZeroLagPVO

y = SignalZL

BullDiv = 0

BearDiv = 0

// BEARISH DIVERGENCES PVO (as in your working MACD code)

hi = max(hi, x)

hico = max(hico, max(High, High[1]))

IF x CROSSES UNDER y THEN

sto2b = sto1b

sto1b = hi

hi = 0

p3b = p1b

p2b = max(p1b, hico1)

p1b = max(Highest[3](High), hico)

IF p2b = p1b THEN

p2b = max(p3b, p4b)

ENDIF

hico = 0

hico1 = 0

ENDIF

IF x < y THEN

p4b = hico1

hico1 = max(hico1, High)

ENDIF

IF p1b > p2b AND sto1b < sto2b AND x CROSSES UNDER y AND x < x[1] THEN

BearDiv = xHistogram

ENDIF

// BULLISH PVO DIVERGENCES

lo = min(lo, x)

lowco = min(lowco, min(Low, Low[1]))

IF x CROSSES OVER y THEN

sto2h = sto1h

sto1h = lo

lo = 100000

p3h = p1h

p2h = min(p1h, lowco1)

p1h = min(Lowest[3](Low), lowco)

IF p2h = p1h THEN

p2h = min(p3h, p4h)

ENDIF

lowco = 100000

lowco1 = 100000

ENDIF

IF x > y THEN

p4h = lowco1

lowco1 = min(lowco1, Low)

ENDIF

IF p1h < p2h AND sto1h > sto2h AND x CROSSES OVER y AND x > x[1] THEN

BullDiv = xHistogram

ENDIF

// RETURN statement (MUST be the last line)

RETURN ImpulseUp COLOURED(0,255,0) AS "Impulse Up (Green)",ImpulseDown COLOURED(255,0,0) AS "Impulse Down (Red)",ImpulseNeutral COLOURED(128,128,128) AS "Impulse Neutral (Gray)",BullDiv COLOURED(0,180,0) AS "Bullish Divergence",BearDiv COLOURED(180,0,0) AS "Bearish Divergence",xHistogram AS "PVO Histogram",0 AS "Zero Line"

2 users thanked author for this post.

Iván,

robertogozzi

Participant

Topics: 29

Replies: 2262

Been thanked: 1315 times
