//| Fractals - adjustable period |
//+------------------------------------------------------------------+
#property link
#property copyright
#property indicator_chart_window
#property indicator_buffers 2
#property indicator_color1 DeepSkyBlue
#property indicator_color2 PaleVioletRed
#property indicator_width1 2
#property indicator_width2 2
//
//
//
//
//
extern string TimeFrame = "Current time frame";
extern int FractalPeriod = 25;
extern double UpperArrowDisplacement = 0.2;
extern double LowerArrowDisplacement = 0.2;
extern color UpperCompletedColor = DeepSkyBlue;
extern color UpperUnCompletedColor = Aqua;
extern color LowerCompletedColor = PaleVioletRed;
extern color LowerUnCompletedColor = HotPink;
extern int CompletedWidth = 2;
extern int UnCompletedWidth = 1;
extern string UniqueID = "FractalTrendLines1";
double UpperBuffer[];
double LowerBuffer[];
string indicatorFileName;
int timeFrame;
bool returnBars;
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
//
//
//
//
//
int init()
{
if (MathMod(FractalPeriod,2)==0)
FractalPeriod = FractalPeriod+1;
SetIndexBuffer(0,UpperBuffer); SetIndexStyle(0,DRAW_ARROW); SetIndexArrow(0,159);
SetIndexBuffer(1,LowerBuffer); SetIndexStyle(1,DRAW_ARROW); SetIndexArrow(1,159);
indicatorFileName = WindowExpertName();
returnBars = TimeFrame=="returnBars"; if (returnBars) { return(0); }
timeFrame = stringToTimeFrame(TimeFrame);
return(0);
}
int deinit()
{
ObjectDelete(UniqueID+"up1");
ObjectDelete(UniqueID+"up2");
ObjectDelete(UniqueID+"dn1");
ObjectDelete(UniqueID+"dn2");
return(0);
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
//
//
//
//
//
int start()
{
int half = FractalPeriod/2;
int i,limit,counted_bars=IndicatorCounted();
if(counted_bars<0) return(-1);
if(counted_bars>0) counted_bars--;
limit=MathMin(MathMax(Bars-counted_bars,FractalPeriod),Bars-1);
if (returnBars) { UpperBuffer[0] = MathMin(limit+1,Bars-1); return(0); }
if (timeFrame!=Period())
{
limit = MathMax(limit,MathMin(Bars-1,iCustom(NULL,timeFrame,indicatorFileName,"returnBars",0,0)*timeFrame/Period()));
for (i=limit; i>=0; i--)
{
int y = iBarShift(NULL,timeFrame,Time[i]);
int x = iBarShift(NULL,timeFrame,Time[i+1]);
UpperBuffer[i] = EMPTY_VALUE;
LowerBuffer[i] = EMPTY_VALUE;
if (x!=y)
{
UpperBuffer[i] = iCustom(NULL,timeFrame,indicatorFileName,"calculateValue",FractalPeriod,UpperArrowDisplacement,LowerArrowDisplacement,UpperCompletedColor,UpperUnCompletedColor,LowerCompletedColor,LowerUnCompletedColor,CompletedWidth,UnCompletedWidth,UniqueID,0,y);
LowerBuffer[i] = iCustom(NULL,timeFrame,indicatorFileName,"calculateValue",FractalPeriod,UpperArrowDisplacement,LowerArrowDisplacement,UpperCompletedColor,UpperUnCompletedColor,LowerCompletedColor,LowerUnCompletedColor,CompletedWidth,UnCompletedWidth,UniqueID,1,y);
}
}
return(0);
}
//
//
//
//
//
for(i=limit; i>=0; i--)
{
bool found = true;
double compareTo = High[i];
for (int k=1;k<=half;k++)
{
if ((i+k)<Bars && High[i+k]> compareTo) { found=false; break; }
if ((i-k)>=0 && High[i-k]>=compareTo) { found=false; break; }
}
if (found)
UpperBuffer[i]=High[i]+iATR(NULL,0,20,i)*UpperArrowDisplacement;
else UpperBuffer[i]=EMPTY_VALUE;
//
//
//
//
//
found = true;
compareTo = Low[i];
for (k=1;k<=half;k++)
{
if ((i+k)<Bars && Low[i+k]< compareTo) { found=false; break; }
if ((i-k)>=0 && Low[i-k]<=compareTo) { found=false; break; }
}
if (found)
LowerBuffer[i]=Low[i]-iATR(NULL,0,20,i)*LowerArrowDisplacement;
else LowerBuffer[i]=EMPTY_VALUE;
}
//
//
//
//
//
int lastUp[3];
int lastDn[3];
int dnInd = -1;
int upInd = -1;
for (i=0; i<Bars; i++)
{
if (upInd<2 && UpperBuffer[i] != EMPTY_VALUE) { upInd++; lastUp[upInd] = i; }
if (dnInd<2 && LowerBuffer[i] != EMPTY_VALUE) { dnInd++; lastDn[dnInd] = i; }
if (upInd==2 && dnInd==2) break;
}
createLine("up1",High[lastUp[1]],Time[lastUp[1]],High[lastUp[0]],Time[lastUp[0]],UpperUnCompletedColor,UnCompletedWidth);
createLine("up2",High[lastUp[2]],Time[lastUp[2]],High[lastUp[1]],Time[lastUp[1]],UpperCompletedColor,CompletedWidth);
createLine("dn1",Low[lastDn[1]] ,Time[lastDn[1]],Low[lastDn[0]] ,Time[lastDn[0]],LowerUnCompletedColor,UnCompletedWidth);
createLine("dn2",Low[lastDn[2]] ,Time[lastDn[2]],Low[lastDn[1]] ,Time[lastDn[1]],LowerCompletedColor,CompletedWidth);
return(0);
}
//
//
//
//
//
void createLine(string add, double price1, datetime time1, double price2, datetime time2, color theColor, int width)
{
string name = UniqueID+add;
ObjectDelete(name);
ObjectCreate(name,OBJ_TREND,0,time1,price1,time2,price2);
ObjectSet(name,OBJPROP_COLOR,theColor);
ObjectSet(name,OBJPROP_WIDTH,width);
}
//-------------------------------------------------------------------
//
//-------------------------------------------------------------------
//
//
//
//
//
string sTfTable[] = {"M1","M5","M15","M30","H1","H4","D1","W1","MN"};
int iTfTable[] = {1,5,15,30,60,240,1440,10080,43200};
//
//
//
//
//
int stringToTimeFrame(string tfs)
{
tfs = stringUpperCase(tfs);
for (int i=ArraySize(iTfTable)-1; i>=0; i--)
if (tfs==sTfTable[i] || tfs==""+iTfTable[i]) return(MathMax(iTfTable[i],Period()));
return(Period());
}
string timeFrameToString(int tf)
{
for (int i=ArraySize(iTfTable)-1; i>=0; i--)
if (tf==iTfTable[i]) return(sTfTable[i]);
return("");
}
//
//
//
//
//
string stringUpperCase(string str)
{
string s = str;
for (int length=StringLen(str)-1; length>=0; length--)
{
int tchar = StringGetChar(s, length);
if((tchar > 96 && tchar < 123) || (tchar > 223 && tchar < 256))
s = StringSetChar(s, length, tchar - 32);
else if(tchar > -33 && tchar < 0)
s = StringSetChar(s, length, tchar + 224);
}
return(s);
}
.
